●Object distance adjustable, could match Myopia degree（0°-700°）；
● Low power consumption, working current 350mA；
● super sensitive 5.8GHz receiver module, strong anti-interference, more stable
signal；
● 40 CH modules, channels Auto-Searching；
● 3.0 inch 480*320 Screen resolution Highlight IPS screen；
● Built in 3.7V/1200mAh Lithium battery；
● TYPE-C charging output；
● Real-time video return, no time delay；
● Support Chinese / English menu；
● Support External video signal input；
● Support Av signal video output, could connect with the external DVR for recording；
Specifications:
|
Item |
VR100 |
||||||||
|
Name |
5.8G FPV Goggle |
||||||||
|
Display |
Screen: 3.0 inch IPS Highlight screen |
||||||||
|
Screen resolution: 480*320 |
|||||||||
|
Ratio: 16:9 |
|||||||||
|
View Angle: 360-degree viewing angle |
|||||||||
|
Backlight brightness: 500cd/m² |
|||||||||
|
video delay |
Less than 10 milliseconds |
||||||||
|
Interface definition |
antenna |
SMA male to RP-SMA female |
|||||||
|
charging |
TYRE-C port charge battery |
||||||||
|
headphone |
3.5mm AV port available for video input and output |
||||||||
|
Language |
Chinese and English |
||||||||
|
Power Supply |
Power adapter: suggest use DC5V/1 or DC/5V2A interface |
||||||||
|
Capacity: Built in 3.7V/8\1200mAh lithium polymer battery |
|||||||||
|
Working power:
*working current: 350 mA *one hour charge fully, can be worked nearly 3 hours |
|||||||||
|
Wireless |
Frequency Table (MHz) |
||||||||
|
|
CH1 |
CH2 |
CH3 |
CH4 |
CH5 |
CH6 |
CH7 |
CH8 |
|
|
Band A |
5865 |
5845 |
5825 |
5805 |
5785 |
5765 |
5745 |
5725 |
|
|
Band B |
5733 |
5752 |
5771 |
5790 |
5809 |
5828 |
5847 |
5866 |
|
|
Band E |
5705 |
5685 |
5665 |
5645 |
5885 |
5905 |
5925 |
5945 |
|
|
Band F |
5740 |
5760 |
5780 |
5800 |
5820 |
5840 |
5860 |
5880 |
|
|
Band R |
5658 |
5695 |
5732 |
5769 |
5806 |
5843 |
5880 |
5917 |
|
|
Appearance |
Dimension: 107mm * 150mm * 75mm |
||||||||
|
Weight: 300g without antenna
|
|||||||||
